- 1.8GHz quad-core ARM Cortex-A72 CPU
- 4GB LPDDR4-3200 DRAM
- VideoCore VI graphics (OpenGL ES 3.1, Vulkan)
- 4kp60 HEVC decode
- True Gigabit Ethernet
- 2 × USB 3.0 and 1 × USB 2.0 ports
- 2 × micro-HDMI ports (1 × 4kp60 or 2 × 4kp30)
- USB-C for input power, supporting 5V 3A operation
- Raspberry Pi-compatible 40-pin horizontal GPIO connector
- Kensington lock
| Processor: | Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.8GHz |
| RAM: | 4GB LPDDR4-3200 |
| Connectivity: | Dual-band (2.4GHz and 5.0GHz) IEEE 802.11b/g/n/ac wireless LAN, Bluetooth 5.0, BLE, Gigabit Ethernet , 2 × USB 3.0 and 1 × USB 2.0 ports, |
| GPIO: | Horizontal 40-pin GPIO header |
| Video & sound: | 2 × micro HDMI ports (supports up to 4Kp60) |
| Multimedia: | H.265 (4Kp60 decode); H.264 (1080p60 decode, 1080p30 encode);OpenGL ES 3.0 graphics |
| SD card support: | MicroSD card slot for operating system and data storage |
| Keyboard: |
78-compact keyboard |
| Power: |
5V DC via USB-C connector |
| Operating temperature: | 0°C to +50°C |
| Dimensions: | 286 mm × 122 mm × 23 mm (maximum) |
| Compliance: |
For a full list of local and regional product approvals, please visit |
